Tubular Inverter batteries

Why Tubular Batteries are most suitable in Inverter Application?

A tubular battery uses technology that seals the active material in polyester tubes called gauntlets, instead of
pasting it on the surface of the plate. As a result, there’s no shedding or corrosion, ensuring long battery life.
Owing to their toughness and durability, tubular batteries can operate at extreme temperatures, and are used in high
cyclic applications involving frequent and prolonged power outages.

The Exide Torr Tubular Advantage

All tubular batteries behave similarly to start with, but obviously, not all tubular batteries are the same. The
difference lies in the composition of the alloy in the positive support structure, as well as in the way that the main
back bone of the plates, called the SPINE, is cast. With the help of Torr Tubular technology, Exide tubular batteries
use the high pressure ‘HADI’ casting process at 100 bar, while most other manufacturers use gravity of low pressure
casting processes. The spines in Exide tubular batteries are cast from low antimony lead alloy, with selenium, copper,
tin, and arsenic, to protect the lead support from anodic corrosion.

A scanning electron microscope (SEM) study reveals the differences in machines that use gravity or low pressure
casting, and those that are ‘HADI’ casting.

Tubular Batteries

EXIDE INVAGO

FEATURES OF EXIDE INVAGO

Thick Tubular Plates

Bottom Mounted Castor Wheels – Cube Container

Top Mounted Tray to House Inverter / Home UPS

Sliding Channels for Topping Up

Registered/Patented Design

No need for External Casing

Type	Part no.:	Ah Capacity @C20	Warranty (Years)	Dimensions ± 3mm Length	Dimensions ± 3mm Width	Dimensions ± 3mm Height	Filled Weight (Kg)
INVAGO1500	FEGO-INVAGO1500	150	4	430	290	400	67.0

Download Product Catalogue

–

EXIDE INVATUBULAR

FEATURES OF EXIDE INVATUBULAR

Premium Range – The Ultimate Inverter Battery

Tough Condition – Tough Battery with Thicker Plates

Long Life – 1200 Cycles @ 80% DOD

More Electrolyte per Ampere Hour

Type	Part no.:	Ah Capacity @C20	Warranty (Months)	Dimensions ± 3mm Length	Dimensions ± 3mm Width	Dimensions ± 3mm Height	Filled Weight (Kg)
IT400	FEIO-IT400	115	42	500	187	416	53.8
IT500	FEIO-IT500	150		500	187	416	59.8
IT500+	FEIO-IT500+	180		401	189	414	60.0
IT750	FEIO-IT750	200		500	187	416	66.0
IT850	FEIO-IT850	230		500	187	416	70.0
