In order to offer the best possible space utilization, and to accommodate the potentially rapid expansion of new IT equipment, modern data centers have implemented a high-density model, based primarily on blade server technology. This model requires a higher power supply density, and can thereby create more significant problems with heat dissipation. In order to address these issues, round-the-clock air conditioning is sometimes deployed as a cooling system solution. However, the expense of using this method for data center cooling can end up accounting for up to 45% of the total electricity expenses incurred by the data center. With this in mind, heat dissipation and electricity expenses are important indices against which operational expenditures of the data center can be measured.
As a leading global manufacturer of fans and a specialist in power management, Delta Electronics was perfectly positioned to develop Delta InfraSuite Precision Cooling solutions in order to provide practical, optimized, innovative methods for data center cooling. Delta’s precision cooling enthalpy laboratory carefully verifies cooling system performance and reliability during the engineering development and design process to ensure high product performance.
Specialized forms of air conditioning and temperature control have been developed to cater to the unique cooling system needs of contemporary data centers. Traditional precision air conditioning is not appropriate in many cases as a data center cooling system. This type of air conditioning cannot provide adequate heat removal for data centers due to the problems of uneven heat distribution, load variations experienced during peak and off-peak periods, and high power density. An optimal data center cooling system must accommodate for each of these factors. Instead of traditional precision air conditioning methods, Delta InfraSuite Precision Cooling solutions employ either chilled water or refrigerant types to remove the heat produced by the hardware within the data center.
Cooling units can be installed in a modular rack design, which enables quick configuration and is readily expandable by load. Data center cooling by water is safe for the equipment it protects due in part to built-in leakage detectors, which can display leaks and offer alerts in a timely manner. With manual dehumidification capacity, Delta’s data center cooling system offers a rapid and precise means of adjusting the level of moisture within the air, and keeping humidity levels within the ideal range required by the data center equipment.
Introduction
With the increasing demand for high performance computing in data centers and the continuous advancement of IT equipment process technology, high thermal design power chips require a new advanced cooling technology. Delta’s two-phase immersion liquid cooling has emerged to meet these new requirements.
Integrating new technology and an innovative mechanism design, Delta’s two-phase process directly immerses electronic parts and equipment in non-conductive coolant, and removes heat through the phase change of the coolant. This improves heat dissipation efficiency by reducing the heat exchange process, which is significantly more efficient than traditional air cooling, reducing energy consumption by 84%.
Features
Introduction
Product available regions :
Because product specifications vary slightly from region to region, please download your local leaflet or visit your local website for detailed product information.
|
The Delta CoolDoor is a rear door cooling unit with EC fans designed for high power density racks and offering high reliability and energy efficiency. Combined with Delta’s CDU or chiller, CoolDoor removes heat at its source without hot air going into the room. CoolDoor is compatible with various racks through its connect duct. It doesn’t need an added footprint and raised floor to save valuable space and reduce the CAPEX of your data center. CoolDoor features a turbo boost function that helps to dissipate heat from an adjacent rack that may have issues. It is also equipped with a leakage detection function that provides an alarm notification to the user or automatically shuts down the water supply when a leakage is detected.
Delta is pleased to customize your CoolDoor units to provide the optimal products for your data center.
Download Product Catalouge
Introduction
Product available regions :
Because product specifications vary slightly from region to region, please download your local leaflet or visit your local website for detailed product information.
|
Delta’s R series uses high-efficiency DC inverter compressors and electronically Commuted (EC) Fans. Using Delta’s best fuzzy control mode, the R series is the highly efficient, outstanding direct expansion (DX) type cooling product. Improving the high efficiency and power density of medium or small sized data center, and offering both convenience and easy maintenance, Delta’s R series is the best choice for optimizing the total cost of ownership (TCO).
Download Product Catalouge
Introduction
Product available regions :
Because product specifications vary slightly from region to region, please download your local leaflet or visit your local website for detailed product information.
|
RowCool for effective heat removal in data centers
Delta’s RowCool CW offers outstanding performance in high temperature chilled water applications via the optimized design of its heat exchanger. With industry-leading high cooling capabilities, the RowCool CW increases the overall cooling efficiency of data center precision cooling systems. The RowCool CW provides the best cooling solutions for data centers over hundreds of kW, focusing on both high efficiency and high density.
Applications:
- High power density rack area
- Environment that requires precise environmental control
features
High Availability
- Built-in dual power supply with dual input for better power reliability
- Rectifiers and fan that support hot swappable, greatly reducing maintenance time
- Panel made of cold-rolled steel plate and coated with surface electrostatic spraying
- Built-in leakage detector capable of leak display and alert
- Modular rack design readily expandable by load to enable quick configuration
- Built-in manual dehumidifying for quick and precise dehumidification
- Supporting group control and used as backup
High Flexibility
- Chilled water pipe suitable for both top and bottom insertion, with flexible configuration as required
- Wheels on bottom for easy moving to locations that need cooling
- Disposable filter with high efficiency (MERV 8 ASHRAE 52.2, 45mm); washable MERV 1 filter is available for purchase to save cost
- Remote monitoring can be carried out through SNMP card, providing more comprehensive system protection
High Efficiency
- To comply with the high power density of racks, the RowCool series cooling capacity can increase up to 60kW (HCH1870) without changing footprint- for RowCool 43kW
- When Applied to the high temperature settings of inlet water, outdoor units save on power consumption by up to 15~20% when the chiller water temperature increases from 5°C to 12°C
- Continuously variable speed fan design for energy saving
- Cooling system capable of variable flow control for energy saving
- Built-in vortex wafer flow meter capable of monitoring chilled water flow that renders easy display of system status
Download Product Catalouge
Introduction
Product available regions :
Because product specifications vary slightly from region to region, please download your local leaflet or visit your local website for detailed product information.
|
RowCool for effective heat removal in data centers
Delta’s RowCool CW offers outstanding performance in high temperature chilled water applications via the optimized design of its heat exchanger. With industry-leading high cooling capabilities, the RowCool CW increases the overall cooling efficiency of data center precision cooling systems. The cooling capacity of a single unit can reach up to 260kW. The RowCool CW provides the best cooling solutions for data centers over hundreds of kW, focusing on both high efficiency and high density.
Applications:
- High power density rack area
- Environment that requires precise environmental control
features
High Availability
- Built-in dual input for better power reliability
- Panel made of cold-rolled steel plate and coated with surface electrostatic spraying of epoxy is highly resistant to rust
- Built-in leakage detector capable of leak display and alert
- Modular rack design readily expandable by load to enable quick configuration of new cooling units
- Built-in manual dehumidifying for quick and precise dehumidification
- Supporting group control and used as backup
High Flexibility
- Chilled water pipe suitable for both top and bottom insertion, with top and bottom input power wiring, providing flexible configuration as required
- Wheels on bottom for easy moving to locations that need cooling
- Disposable filter with high efficiency (MERV 8 ASHRAE 52.2)
- Remote monitoring can be carried out through SNMP card, providing more comprehensive system protection
- Optional reheater and humidifier accessories for more precise temperature and humidity control
High Efficiency
- To comply with the high power density of racks, the RowCool series cooling capacity can increase up to 120kW (HCH1CD0) without changing footprint- for RowCool 43kW
- When Applied to the high temperature settings of inlet water, outdoor units save on power consumption by up to 15~20% when the chiller water temperature increases from 5°C to 12°C
- Continuously variable speed fan design for energy saving
- Cooling system capable of variable flow control for energy saving
- Built-in vortex wafer flow meter capable of monitoring chilled water flow that renders easy display of system status
Download Product Catalouge
Introduction
Product available regions :
Because product specifications vary slightly from region to region, please download your local leaflet or visit your local website for detailed product information.
|
For data centers with raised floors, the space beneath the floors is usually used as the cold aisle to deliver cold air to the IT racks. In data centers with this type of architecture, the amount of cold air that can be received by each IT rack depends on the static pressure of the cold aisle, the opening areas on floors as well as the suction capability of the racks. If any of these three criteria are insufficient, the rack will face the problem of insufficient supply of cold air and result in overheating.
The Delta ADU provides data centers with a simple solution for hot spots at the end of an aisle or for overheated high power density racks. Delta’s ADU installs under the original openings of a raised floor where it detects the temperature inside a target rack or hot spot. The ADU automatically adjusts the rotation speed of its electronically commutated (EC) fan to provide the cool air needed by the target rack or hot spots.
Applications:
- High power density rack area
- Environment that requires precise environmental control
features
High Availability
- Maximum airflow above 1000 CFM.
- Inherent redundancy design if a fan malfunctions, other fans automatically increase in speed to make up the required airflow.
- The EC fan uses internal temperature data feedback of the target rack to automatically adjust fan speed and achieve the required rack temperature.
- Installs directly under raised floors with common openings – no need for special raised floors.
- Four dry contact outputs and one input for administrators to monitor and control.
